Description
Universal Testing Machine QC-503M2F is capable for test capacity up to 100KN. High rigid frame structure and precise servo motor transmission parts supply offer stable machine operation for our universal testing machines. Suitable for plastic, textile, metal, architecture and construction industry, and also provide quiet testing environment and high accuracy test result.
Equipped with Cometech’s advanced M2F controller system, the tensile testing machine can perform creep, constant compression, cycle, multi-step test mode, which conforms to various tensile, compression, bending, peeling, and compression tests. The M2F software has multi-languages and is very easy to handle. Not only does the universal tensile test machine has all kind of metric units and real-time graphics but it also provides complete analysis test data which can do variety of material analysis after the test.
The separate design of the tensile machine and controller make maintenance a lot easier. Decrease the maintenance fee efficiently, and greatly extend the life time of machine. In addition, the speed of M2F system is capable for 0.0001-375mm/min to increase the testing range and satisfy more standard requirement.
Conform to Standards
- ISO 7500-1
- ASTM E4
- JIS 475-88
- JIS B7721
- JIS B7733
- DIN 5122
- BS EN 1002-1
- BS 1610
- GB/T T228
Industry
Plastic, Textile, Metal, Architecture
Catalog Download
QC-503M2F Universal Materials Testing Machines
Testing Video
Specifications
Max. Capacity
100kN
Force Resolution
1/100,000 (31 bits)
Test Stroke(w/o grip)
1100mm
Speed Range
0.0001~375 mm/min
Data sampling rate
Max.1200Hz
Motor
Servo Motor
Dimension
135 X 60 X 220cm
Weight
800 kg
Feature
1. Designed for creep, cycle, load/strain control, foam testing, possion's ratio, slippage, etc.
2.More than 260 software analysis available
3.Equipped with jog controller to adjust displacement precisely
4.Optional anti-collision function for protecting loadcells
5.Loadcell automatic reading, calibrated without installed on machine
Accessories
Displayer
-7" color touch TFT display panel is used.
-Chinese, English, Japanese are supported.
-Displays force, pressure, displacement and time.
-Supports test speed, direction, auto-return, stop at the break point as test conditions.
-Can analyze max. force, interval force, force at break point, and so on.
-Provides multiple stop condition settings including force, displacement, time and elongation.
-Supports over travel, overload, overtime stop protection settings.
-Can save up to 50 test results; it also supports saving to USB.
-Restore the machine to factory setting is available.
-Can calibrate with stand-alone mode.
-Supports switching between Metric and Imperial units.
QC-551 Long Extensometer
QC-551 Long extensometer is suitable for higher than 20% elongation of rubber, plastic, PE, fabric, webbing of material which are high elongation measurement accessories. The specimen usually made dumbbell-shape. The extensometer can link with Cometech machine and auto-detect the deformation of the test piece during the test.
QC-557 Short extensometer
QC-557 Short extensometer can measure metal, hard plastic of less than 100% elongation of material deformation. During test, it can measure complete test deform rate and do not need to dismantle it when during the test. When the specimen gauge length is longer or elongation rate is bigger, customized longer extensometer is also available.
Software functions
-The data sampling rate is up to 1200 Hz.
-Controlled by mouse, keyboard and the up/down button on the machine to quick-adjust the position of grip.
-Windows system required.
-Chinese, English, Japanese, Korean, Portuguese, Polish, Spanish and Russian are available.
-Operation Mode: TCP/IP two-way transmission to connect with PC.
-Can import multiple test data and display at the same time.
-Supports Metric and Imperial units switching.
-Provides a flexible table for data analysis.
-Can name the data results and create a user-defined formula.
-Data can be shown through the table, graph, or both.
-Data processing: save, import, list, statistical comparison, and so on.
-The X-Y axis of the graph is adjustable including marks on the curve, interval marks, slope, and so on.
-Tensile, compression, bending, peeling, spring, creep and others are available.
-Supports over travel, overload, over time stop conditions as machine protection.
-Supports various test patterns such as reciprocation, creep, constant tensile (compression), test pause, slippage, 10-stage settings, and so on.
-Specimen modular design is for easy and quick specimen information setting.
-Test condition modular design can reduce man-made setting error.
-Supports upper and lower limits for data selection to get the key information.
-Supports multiple I/O ports for the additional test functions.
