Manual Roller-QC-803A Motor Type Roller-QC-803H

QC-803A/H
Manual Roller
Motor Roller

Send us an Inquiry

Description

The preparation of samples for tape peeling tests is performed using a standard rubber roller to roll and adhere the tape onto a steel plate or specific material. Manual application of the tape can be inconsistent and easily affect the test results. However, by using an electric rolling roller to make the samples, the consistency and stability of the adhesion can be ensured. The QC-803H operating interface features a 5-inch touchscreen, providing a simple and clear user interface. The rolling speed can be freely set between 50 to 1200mm/min, and up to 99 reciprocating rolls and a maximum adhesive distance of 300mm can be programmed.

Conform to Standards

  • JIS C2107
  • JIS Z0237
  • PSTC 107
  • ASTM D3330
  • ASTM D1000

Industry

Tape, Packaging

Catalog Download

QC-803A/H Roller Tester

Specifications


Model

QC-803A/ QC-803H

Weight of roller

4.5LB ( On model H, two roller can be used at the same time)
Surface with rubber 80 ±5°(Shore A),Rubber coating 6 mm

Speed of roller

A: Control by hand
H: 50 ~ 1200 ±5% mm/min (adjustable)

Stroke

A: Control by hand
H: Max.300
(Make a round trip automatically)

Width of Roller

45 ± 1.5 mm

Diameter of Roller

97 ± 2.5 mm

Roll cover: Rubber to hardness scale

80°±5°(Shore A)

Power

A:NA
H: Single phase,100 ~ 240V

Dimension

A: 14 × 22 × 8 cm
H: 58 × 35 × 28 cm

Weight

A: 2.5 kg
H: 33 kg
